Roofing Construction Gallery
The following thumbnail photos illustrate common roofing problems. Click on the thumbnail for enlargement of the image. Contact us for more details.
- Shingle roof with organic felt underlayment.
- Installing insulation in hot bitumen.
- Installation of polyisocyanurate insulation and fibreboard overlay insulation.
- Installation of Kraft paper on gypsum board by use of hot asphalt.
- Torch applying modified cap flashing to a curb detail on a built up type 4 glass felt application.
- Mop application of organic felt membrane.
- Mop application of 4 ply organic felt.
- Application of pea gravel in hot asphalt.
- Mop application of organic felt at a control joint repair.
- Installing a wood nailer at the top of a firewall prior to application of ice and water shield membrane.
- Tapping the joint of asphalt primed gypsum board.
- Torch application of modified cap sheet for a modified bitumen roof system.
- Fitting of modified base flashing at edge detail.
- Installation of metal flashing at a vent stack.
- Construction of a new control joint.
- Installation of 2 part PVC flashing detail.
- Illustration of a PVC walkway.
- Installation of new metal decking and application of rust inhibitor.
- Installation of insulation for an inverted roof application.
- Torch application of a modified membrane.
- Polyisocyanurate insulation is mechanically fastened to deck. Note new cant strips applied to curb detail.
- Adhering of EPDM flashing at curb detail.
- Marley concrete tile roof system.
- Illustration of fall restraint system.
- Finished tapered 2 ply modified bitumen roof.
- Installation of an EPDM loose laid ballasted roof system.
- Lay out of filter fabric sheet for an inverted roofing system.
- Ballast being placed over filter fabric sheet.
- Installation of a shingle roof.
- Shingle roof with ice and water protection and organic felt underlay.
- View of completed PVC roof application at Air Traffic Control building Pearson International Airport.
- Mop application of No.15 felt in asphalt.
- Completed two ply modified roof.
- View of a common roofing site.
- Installing tapered insulation on a roof.
- Installation of filter fabric sheet inverted roof.
- Standing seam metal roof panel.
- Modified base sheet flashing.
- Modified base sheet flashing for wall detail.
- Installing EPDM loose laid ballasted membrane.
- Filter Sheet and ballast for inverted roof.
- Standing seam metal roof panel.
- Completion of modified base sheet membrane application.
- Torch application of modified cap sheet membrane.
- View of a typical roof under construction.
- View of completed 2 ply modified roofing.
- Priming of concrete deck prior to application of insulation.
- Removal of saturated phenolic insulation.
- Removal of water damaged roof.
- Mop applying No. 15 organic felt vapour retarder.
